Ultra – Self Bailer – Standard PVC (700mmL x 80mmW x 80mmH) 0.4L
Automatic self-bailer with hydrocarbon shut-off designed for safe drainage of water from containment areas. Features gravity-fed operation, corrosion-resistant PVC construction, and replaceable internal filter media for long-term industrial use.
$726.00 $660.00
SHS-CHU9935 Ultra-Self Bailer Standard PVC (700mmL x 80mmW x 80mmH) 0.4L
Automatic Hydrocarbon Shut-Off Self-Bailer for Safe Liquid Drainage
Overview
The CHU9935 Ultra-Self Bailer Standard is a reliable, gravity-fed drainage solution designed for safe removal of water from spill containment systems while preventing hydrocarbon discharge. It is ideal for use in bunded areas, wash bays, and containment zones where environmental protection is critical.
This self-bailer uses a proprietary polymer filtration system that automatically reacts when hydrocarbons are present. The internal media expands upon contact with oils and fuels, instantly sealing the unit to prevent contamination from escaping.
Constructed from rigid, corrosion-resistant PVC, the unit is built for durability in harsh industrial environments. Its passive operation requires no power, making it a low-maintenance and dependable solution for long-term use.
Key Features & Benefits
Automatic Hydrocarbon Shut-Off
Internal polymer media expands on contact with hydrocarbons to block flow.
Gravity-Fed Operation
No power required, allowing continuous passive drainage.
Corrosion-Resistant PVC
Durable construction suitable for harsh industrial environments.
Efficient Water Flow
Maintains steady drainage of clean water while preventing contamination.
Replaceable Filter Cartridge
Internal media can be replaced for extended product life.
Manual Override Valve
Integrated shut-off valve allows manual control when required.
Compact & Lightweight
Easy to install and handle in various containment setups.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Code | CHU9935 |
| Length | 700mm |
| Width | 80mm |
| Height | 80mm |
| Weight | 1.4kg |
| Containment Capacity | 0.4 Litres |
| Material | Rigid PVC (Polyvinyl Chloride), corrosion-resistant |
| Internal Media Type | Proprietary polymer blend (hydrocarbon-reactive) |
| Liquid Holding Capacity | 170–237 mL |
| Hydrocarbon Cut-Off Volume | 207–296 mL |
| Flow Rate (Clean Water) | 28–29 L/h at 50 mm head pressure |
| Operating Principle | Gravity-fed passive drainage with automatic shut-off |
| Connection Type | Bulkhead fitting (standard thread) |
| Replaceable Components | Internal filter cartridge |
| Manual Override | Integrated on/off shut-off valve |
| Installation Orientation | Vertical mount at lowest point of containment |
| UV Resistance | Yes (-20°C to +60°C) |
| Country of Origin | USA |
| HS Code | 8421.21 |
| Workmanship Warranty | 1 Year |
Best Fit For
Spill containment bunds
Wash bays and wash-down areas
Industrial drainage systems
Fuel and oil containment zones
Environmental compliance applications
Not Suitable For
High-pressure pumping systems
Continuous heavy-flow drainage
Applications without proper containment setup
Related Products
Replacement Filter Cartridge
Spill Containment Bunds
Truck Wash Mats
Drainage Control Systems
Download Product Brochure
| Weight | 1.4 kg |
|---|---|
| Dimensions | 35.6 × 17.8 × 12.7 cm |
