Ultra – Drum Funnel Burp Free, Standard (340mmL x 340mmW x 280mmH)
Burp-free drum funnel with hinged lid for splash-free, controlled liquid transfer.
Prevents airlocks and improves safety when filling drums.
$275.00 $250.00
SHS-CHU0651 Ultra-Drum Funnel Burp-Free (340mm)
Burp-Free Drum Funnel with Hinged Lid for Safe, Splash-Free Liquid Transfer
Overview
The CHU0651 Ultra-Drum Funnel Burp-Free is designed to eliminate splashback and “burping” during liquid transfer into drums, improving safety and efficiency in hazardous environments.
Its innovative burp-free design allows smooth, continuous pouring by preventing airlocks, while the large internal drainage area ensures fast liquid flow. Constructed from durable polyethylene, it offers excellent chemical resistance and long-term reliability.
A hinged, lockable lid keeps contaminants out and helps maintain site compliance, making it ideal for industrial, chemical, and waste handling applications.
Key Features & Benefits
Burp-Free Design
Prevents splashback and airlock “burping” during pouring.
Large Drainage Area
Improves flow rate and reduces liquid pooling.
Hinged Lockable Lid
Keeps contaminants out and enhances site safety.
Fits Standard Drum Bung
Compatible with 50mm NPT openings on steel and plastic drums.
Durable Polyethylene Construction
Strong, chemical-resistant and impact resistant.
UV Stabilised
Suitable for indoor and outdoor use.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Code | CHU0651 |
| Length | 340mm |
| Width | 340mm |
| Height | 280mm |
| Weight | 2kg |
| Material | 100% Polyethylene |
| Interior Drainage Space | 165mm (H) x 230mm (Dia) |
| Burp-Free | Yes |
| Lid | Hinged |
| Lockable | Yes |
| Compatibility | Fits 50mm NPT drum bung openings |
| UV Resistance | Contains UV inhibitors |
| Chemical Resistance | Acids, alkalis, hydrocarbons |
| Flammable Liquids | Not recommended (flash point < 60.56°C) |
| Country of Origin | USA |
| HS Code | 3926.90 |
| Warranty | 1 Year |
Best Fit For
Drum filling without splashback
Hazardous liquid handling
Waste liquid transfer
Controlled decanting
Not Suitable For
Flammable liquids (low flash point)
High-pressure transfer systems
Download Product Brochure
| Weight | 2.7 kg |
|---|---|
| Dimensions | 43.2 × 35.6 × 38.1 cm |
