HIW50 Electric Scissor Lift Table- 500kg Capacity / 1.1m Lift Height
$3,503.95 $3,185.41
Description
Single Scissor Electric Scissor Lift Table- 1.1m Lift Height / 500 Capacity
Engineered to provide reliable extra lifting height, this single scissor lift table is suitable for both above-floor and in-floor pit applications.
Safety Features
- Internal Power Pack: Equipped with a relief valve to prevent overloading and a compensated flow valve for smooth, controlled lowering.
- Dual Safety Solenoid Valves: One at the pump and one at the cylinder to prevent unintended descent in the event of hose failure.
- Aluminium Safety Bar: Fitted beneath the upper platform to stop descent upon contact with obstructions.
- Low-Voltage Controls: 24V control box with simple up/down and emergency stop push buttons.
- Goods-Only Design: Intended strictly for lifting goods and products.
- Removable Eyelets: For safe and convenient lifting/handling of the table itself.
Removable Eyelets for lifting
|
Model |
HIW50 |
|
Capacity |
500kg |
|
Lowered Height |
190mm |
|
Raised Height |
1010mm |
|
Platform Size |
L1300xW800 |
|
Lifting Time |
15s |
|
Lifting Speed with Load |
55mm/s |
|
Lowering Speed with Load |
40mm/s |
|
Motor |
0.75Kw |
|
Hydraulic Cylinder |
1unit |
|
Net Weight |
160kg |
Optional Add-Ons: Trolley Frame / Wheels: Loading Flap, Recessed Circular Turntable, Pallet Truck Frame, Side Barrier Rails, Raise & Tilt Platform, Roller Bed, Foot Control, 240V or 3 Phase Power, Custom Table Size, Protection Curtain- contact us for a tailored quote on any add-on options.
<!–
Shipping:
- We ship our products to all over Australia.
–>
| Weight | 195 kg |
|---|---|
| Dimensions | 140 × 90 × 30 cm |
