Ultra – Self Bailer – Large PVC (910mmL x 110mmW x 114mmH) 0.8L
High-capacity self-bailer designed for safe drainage of water from spill containment areas. Features automatic hydrocarbon shut-off, high flow rate, and durable PVC construction for reliable performance in demanding industrial environments.
$1,419.00 $1,290.00
SHS-CHU9937 Ultra-Self Bailer Large PVC (910mmL x 110mmW x 110mmH) 0.8L
High-Capacity Self-Bailer with Automatic Hydrocarbon Shut-Off for Spill Containment Systems
Overview
The CHU9937 Ultra-Self Bailer Large is a high-capacity drainage solution designed to safely remove clean water from spill containment areas while preventing hydrocarbons from escaping. It is ideal for larger bunds and outdoor containment systems where rainwater accumulation can significantly reduce available capacity.
This self-bailer features advanced hydrocarbon-reactive internal media that expands upon contact with oils and fuels, automatically sealing the unit to prevent environmental contamination. Its gravity-fed operation ensures continuous drainage without the need for power, making it ideal for remote or unmonitored locations.
Constructed from rigid, corrosion-resistant PVC, the unit is built to withstand harsh industrial environments. With increased flow rate and capacity compared to standard models, it provides efficient performance for higher-volume drainage applications.
Key Features & Benefits
Automatic Hydrocarbon Shut-Off
Internal polymer media expands to block flow when hydrocarbons are detected.
High Flow Rate
Handles up to 84 L/h for faster drainage of clean water.
Large Capacity Design
Ideal for larger containment areas and higher water volumes.
Passive Operation
Gravity-fed system requires no power for continuous operation.
Durable PVC Construction
Corrosion-resistant material designed for industrial environments.
Replaceable Filter Cartridge
Extends product life with easy maintenance.
Manual Shut-Off Valve
Integrated valve allows controlled operation and servicing.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Code | CHU9937 |
| Length | 910mm |
| Width | 110mm |
| Height | 110mm |
| Weight | 3kg |
| Containment Capacity | 0.8 Litres |
| Material | Rigid PVC (Polyvinyl Chloride), corrosion-resistant |
| Internal Media Type | Proprietary polymer blend (hydrocarbon-reactive) |
| Liquid Holding Capacity | 620–830 mL |
| Hydrocarbon Cut-Off Volume | 770–950 mL |
| Flow Rate (Clean Water) | 84 L/h at 50 mm head pressure |
| Operating Principle | Gravity-fed passive drainage with automatic shut-off |
| Connection Type | Bulkhead fitting (standard thread) |
| Replaceable Components | Internal filter cartridge |
| Manual Override | Integrated on/off shut-off valve |
| Installation Orientation | Vertical mount at lowest point of containment |
| UV Resistance | Yes (-20°C to +60°C) |
| Country of Origin | USA |
| HS Code | 8421.21 |
| Workmanship Warranty | 1 Year |
Best Fit For
Large spill containment bunds
Outdoor fuel and chemical storage areas
Industrial wash-down zones
Construction and mining sites
High-volume water drainage applications
Not Suitable For
High-pressure pumped systems
Continuous heavy liquid discharge
Applications without containment systems
Related Products
Ultra-Self Bailer Standard (CHU9935)
Replacement Filter Cartridge
Spill Containment Bunds
Drainage Control Systems
Download Product Brochure
| Weight | 2.4 kg |
|---|---|
| Dimensions | 41.3 × 16.5 × 15.9 cm |
