All Terrain Electric Pallet Jack- 2T Capacity
$13,365.00 $12,150.00
Available on backorder
When you need to move pallets outside of the warehouse, the KMT series cannot be beat. Perfect for nurseries and tile companies, where moving pallets over unsealed ground is a must. With ample power and superior wheels, rock, dirt and gravel don’t stand a chance – you’ll wonder how you ever did the job without it!
| Distinguishing mark | |
| 1.1 Manufacturer | KM Terrain |
| 1.2 Model designation | Â KMT-2003 |
| 1.3 Rated Capacity | 2000kg |
| 1.4 Load centre | 600mm |
| 1.5 Wheelbase | 1100mm |
| Weights | |
| 2.1 Service weight (including battery): | 665kg |
| Types, Chassis | |
| 3.1 Tyre Type Drive Wheel/ Load Wheels | Rubber/Rubber |
| 3.2 Tyre Size, Drive Wheel (diameter x width) | 300x125mm |
| 3.3 Tyre Size, Load Wheel: (diameter x width) | 406x110mm |
| Dimensions | |
| 4.1 Lift Height | 330mm |
| 4.2 Height drawbar in driving position Min/Max | 880/1250mm |
| 4.3 Lowered Height | 50mm |
| 4.4 Overall Length | 1700mm |
| 4.5 Overall width b | 1575mm |
| 4.6 Fork Dimensions | 40/100/1070mm |
| 4.7 Fork Carriage Width | 840mm |
| 4.8 Outside Width of Forks | 840 mm |
| 4.9 Distance Between legs | 1270mm |
| 4.10 Ground Clearance Below mast | 100mm |
| 4.11 Turning Radius | 1750mm |
| Performance Data | |
| 5.1 Travel Speed, Laden/Unladen | 3.5/7km/h |
| 5.2 Max Gradeability, Laden/Unladen | 5/10% |
| 5.3 Service brake type | Electromagnetic |
| 5.4 Lift Speed with Load | 13mm |
| Electric engine | |
| 6.1 Drive Motor Rating | AC 1.5KW |
| 6.2 Lift Motor Rating | DC 24V/1300W |
| 6.4 Battery Voltage/nominal capacity K5 | 2x12V/100aH |
| 6.5 Battery Weight | 70kg |
| 6.6 Controller | 1232E-2121 Curtis |
| Addition data   | |
| 7.1 Type of Drive Unit | AC |
| 7.2 Steering type | Mechanical |
| 7.3 Sound Pressure level at the driver’s ear | 74 |
| Weight | 700 kg |
|---|---|
| Dimensions | 170 × 160 × 120 cm |
