Fence Boom 15mL,185mm Freeboard, 430mm Draft, 610gsm Yellow PVC

SHS-CHFB01 Fence Boom (15m, 185mm Freeboard, 430mm Draft)

High-Stability Fence Boom for Flowing Water & Drainage Applications

Overview

The CHFB01 Fence Boom is a high-performance containment solution specifically designed for use in moving water, stormwater systems, and drainage channels. Its fence-style construction allows the boom to maintain an upright profile, making it highly effective at capturing oils, debris, and contaminants in flowing conditions.

Manufactured from durable 610gsm yellow PVC with a gloss acrylic coating, the boom offers excellent resistance to UV exposure, chemicals, and harsh environments. Reinforced with supportive webbing and integrated marine battens, it ensures superior structural stability and long-term performance.

Key Features & Benefits

Fence-Style Vertical Design
Maintains upright structure in flowing water for improved containment.

15m Spill Containment Length
Ideal for drains, waterways, and medium-scale spill zones.

Marine Battens for Stability
Enhances rigidity and prevents collapse in current.

Heavy-Duty PVC Construction (610gsm)
Built for demanding industrial and environmental conditions.

185mm Freeboard / 430mm Draft
Provides effective surface and subsurface containment.

Supportive Webbing Reinforcement
Strengthens flotation and ballast structure.

Universal ASTM Z-Connectors
Allows multiple booms to be linked for extended coverage.

Integrated Handles
Simplifies deployment and retrieval.

UV & Chemical Resistant
Suitable for long-term outdoor use.

Wide Temperature Range
Operates from -20°C to +70°C.

Technical Specifications

Optional Accessories

Tow bridle for deployment
Solid filled containment boom for extended systems

Best Fit For

Stormwater drains and culverts
Fast-flowing waterways
Industrial discharge areas
Construction and civil sites

Not Suitable For

Calm water applications where standard booms are sufficient
Permanent installation without inspection
