Dewatering Bag (2.5mL x1.5mW) 200mm neck located on width

SHS-CHDWB03 Chatoyer Dewatering Bag – 2.5m x 1.5m (200mm Neck)

High-Performance Silt & Sediment Control for Large-Volume Dewatering Applications

Overview

The CHDWB03 Chatoyer Dewatering Bag is engineered to efficiently capture silt, sediment, and suspended solids during high-volume dewatering operations on construction, mining, and environmental sites. Measuring 2.5 metres in length and 1.5 metres in width, this large-capacity filtration solution provides a controlled method for discharging water while preventing contaminants from entering stormwater systems or surrounding environments.

Constructed from 270gsm non-woven geotextile fabric, the bag allows water to pass through while retaining suspended solids with 99.0% filter efficiency. The integrated 200mm diameter neck, positioned on the short side/top of the bag, ensures easy connection to large-diameter discharge hoses for efficient and secure operation. With a 1m³ sediment capacity, it is ideal for extended dewatering projects.

Key Features & Benefits

High-Efficiency Sediment Filtration
Captures silt, sand, and suspended solids with 99.0% filter efficiency during pumping operations.

Large Sediment Capacity
1m³ sediment retention capacity for extended use before cleaning or replacement.

Durable Geotextile Construction
270gsm non-woven geotextile with 238kg puncture resistance and 29kg/cm² Mullen burst strength.

High Flow Rate Design
60L/m²/sec flow rate ensures efficient dewatering while maintaining filtration performance.

UV Resistant
Retains 70% strength after 500 hours UV exposure for outdoor durability.

Easy Hose Connection
200mm diameter neck enables quick and secure attachment to large discharge hoses.

Environmental Compliance
180 micron pore size helps meet erosion and sediment control requirements.

Simple Deployment
Lightweight and easy to position on-site with minimal labour required.

Technical Specifications

Performance Features

Efficient removal of suspended solids during high-volume dewatering
99.0% filter efficiency for superior sediment capture
High flow rate of 60L/m²/sec maintains pumping performance
Large 1m³ sediment capacity for extended operations
UV resistant fabric for outdoor durability
Puncture and burst resistant construction

Applications

Construction site dewatering
Mining and industrial water discharge
Stormwater management
Excavation and trench works
Sediment control basins
Environmental protection projects
Large-scale pumping operations

Best Fit For

High-volume dewatering operations
Sites requiring sediment control compliance
Contractors managing large water discharge volumes
Projects with extended pumping durations
Areas needing 99% filtration efficiency

Not Suitable For

High-pressure pumping without flow control
Chemical or hazardous liquid filtration
Permanent filtration systems
Applications requiring sub-micron filtration
