Dewatering Cube (0.9mL x 0.9mW x 1.1mH) 200mm neck on top

SHS-CHDWB05 Chatoyer Dewatering Cube – 0.9m x 0.9m x 1.1m (200mm Neck)

High-Capacity Silt & Sediment Control for Space-Constrained Dewatering Applications

Overview

The CHDWB05 Chatoyer Dewatering Cube is specifically designed to efficiently capture silt, sediment, and suspended solids in areas where horizontal space is limited. Measuring 0.9 metres in length, 0.9 metres in width, and 1.1 metres in height, this vertical filtration solution provides a compact footprint while offering substantial 0.8m³ sediment capacity for dewatering operations on construction, mining, and environmental sites.

Constructed from 270gsm non-woven geotextile fabric, the cube allows water to pass through while retaining suspended solids with 99.0% filter efficiency. The integrated 200mm diameter neck, positioned on the top of the bag, ensures easy connection to discharge hoses for efficient and secure operation in tight spaces.

Key Features & Benefits

Space-Efficient Design
Vertical cube configuration provides 0.8m³ sediment capacity in a compact 0.9m x 0.9m footprint, ideal for congested sites.

High-Efficiency Sediment Filtration
Captures silt, sand, and suspended solids with 99.0% filter efficiency during pumping operations.

Durable Geotextile Construction
270gsm non-woven geotextile with 238kg puncture resistance and 29kg/cm² Mullen burst strength.

High Flow Rate Design
60L/m²/sec flow rate ensures efficient dewatering while maintaining filtration performance.

UV Resistant
Retains 70% strength after 500 hours UV exposure for outdoor durability.

Easy Top-Mounted Hose Connection
200mm diameter neck located on top of the cube enables quick and secure attachment to discharge hoses.

Environmental Compliance
180 micron pore size helps meet erosion and sediment control requirements.

Simple Deployment
Lightweight and easy to position on-site with minimal labour required.

Technical Specifications

Performance Features

Efficient removal of suspended solids during dewatering operations
99.0% filter efficiency for superior sediment capture
High flow rate of 60L/m²/sec maintains pumping performance
Vertical design maximizes capacity in minimal footprint
UV resistant fabric for outdoor durability
Puncture and burst resistant construction
Top-mounted 200mm neck for easy hose connection

Applications

Construction site dewatering in space-constrained areas
Mining and industrial water discharge
Stormwater management in urban environments
Excavation and trench works
Sediment control basins with limited footprint
Environmental protection projects
Tight access sites requiring vertical filtration

Best Fit For

Sites with limited horizontal space
High-volume dewatering requiring compact footprint
Projects needing 99% filtration efficiency
Contractors working in congested urban areas
Temporary dewatering in constrained locations

Not Suitable For

High-pressure pumping without flow control
Chemical or hazardous liquid filtration
Permanent filtration systems
Applications requiring sub-micron filtration
Sites with unlimited horizontal space (use standard bag)
